The main technical information of the product
Product Name: Sprinkler
Dimensions (mm): 10100,10580×2500×2950,3850
Chassis Model: EQ1250GLJ2
Cargo compartment size (mm): × ×
Total mass ：(kg) 25000
Approach/departure angle(° ) 21/10,21/8
Rated mass:(kg) 14225,12225
Front/Rear Overhang(mm): 1450/3000,1450/3480
Overall mass:(kg) 10580,12580(Kg)
High speed(km/h): 90
Emission standard: GB17691-2005

National V,GB3847-2005
Chassis parameters
Chassis Model: EQ1250GLJ2
Axle load: 7000/18000
Number of axles: 3
Fuel Type: Diesel
Wheelbase(mm): 4350+1300,4750+1300,5900+1300
Front wheelbase(mm): 1940
Cab occupancy: 3
Rear wheel spacing(mm): 1860/1860
Number of tyres: 10 Number of springs: 8/12,9/10
Tyre specification: 10.00-20,10.00R20,11.00-20,11.00R20,295/80R22.5
Description of the whole vehicle: 1, optional without sprinkler platform and optional with spraying unit. 2, transport medium: water, density: 1000 kg / cubic metre, vehicle size (length × width × height) / front overhang / rear overhang / tank dimensions (long × long axis × short axis) / mass correspondence: a, with sprinkler platform, the effective volume of the tank: 14.93 cubic metres, 10,100 × 2,500 × 2950/1450/3000/6600 × 2300 × 1450/10580 b, without sprinkling platform, tank effective volume: 14.93 cubic metres, 10100 × 2,500 × 2950/1450/3000/6600 × 2300 × 1450/10580 b, without the spraying platform, and optional with spray unit. 1450/10580 b. Without sprinkler platform, the effective volume of the tank: 14.93 cubic metres, 10100 × 2500 × 2950/1450/3000/7200 × 2100 × 1450/10580 c. With spraying unit, the effective volume of the tank: 12.83 cubic metres, 10580 × 2500 × 3850/1450/3480/5000 × 2400 × 1450/3480/5000 × 2400 × 2400 × 1450/3480/5000 × 2400 × 2400 × 2400 × 2400 × 2400 × 2400 × 2450/3480 3480/5000×2400×1550/12580 3, protection material: Q235A carbon steel, connection: left and right side and rear lower protection are welded connections, rear lower protection section size (mm): 150×50, rear lower protection height above ground (mm): 460. 4, ABS model 3631010-C2000, manufacturer for the East Cork Knorr-Bremse Commercial Vehicle Braking System (Shiyan) Co. 5, Text spraying position, vehicle colour and local details can be changed. 6、Optional cab with chassis.

Engine parameters
Engine Model
ISB210 50
YC6JA240-50
Engine Manufacturer
Dongfeng Cummins Engine Co.
Guangxi Yuchai Machinery Co.
Displacement (ml)
5900
6870
Power (kw)
155
177
